Product · LT-AUTO
Automobile Elevators
Car parking lifts · 2500–5000 kg · turntable optional
Engineered automobile elevators for Pakistan's demanding built environment.
Liftech Global automobile elevators move sedans, SUVs and light commercial vehicles between parking decks in showrooms, high-rise residences and stacked parking facilities. A wide, low-profile cabin with a heavy-duty reinforced sling accepts vehicles up to 5000 kg gross weight; an optional in-cabin turntable rotates the car 180° so drivers exit forward.
The automobile lift is engineered to EN 81-31 goods-only rules with additional PEC electrical compliance and low ride quality tuned for a driver-in-cabin operation.
Where it is deployed.
Why engineers choose this platform.
Wide platform
Cabin up to 3000×6000 mm accepts SUVs and light trucks.
180° turntable
Optional in-cabin turntable eliminates reverse parking.
Heavy payload
Rated load 2500–5000 kg with reinforced 6-rope sling.
Driver-in-cabin
Ride quality tuned for driver + passenger occupancy.
Verified engineering data.
| Parameter | Value |
|---|---|
| Rated load | 2500 · 3500 · 5000 kg |
| Rated speed | 0.25 · 0.4 · 0.5 m/s |
| Travel / stops | Up to 30 m · up to 8 stops |
| Cabin size | 2400×5500 · 2800×6000 · 3000×6000 mm |
| Door opening | 2500–2800 mm center-opening |
| Roping | 6-rope Ø13 mm, 2:1 roping |
| Drive system | PMSM gearless or geared 2:1 |
Engineering highlights.
- In-cabin turntable (optional)
- Traffic-light call & departure indication
- Reinforced cabin floor with anti-slip finish
- Wide vision panels & CCTV integration
- Vehicle-height laser scanner with overheight lockout
Safety by design — every layer.
- Overload & overheight lockouts
- Progressive safety gear (both directions)
- Door-lock and slack-rope monitoring
- Emergency lighting & two-way voice alarm
Codes we design & test to.
- EN 81-31 (goods with driver)
- EN 81-20/50
- ISO 8100-1
- PEC electrical code
See it in the field.
Automobile Elevators: what engineers ask.
End-to-end lifecycle support.
Request a quotation for automobile elevators.
Send us your building drawings and traffic profile — our engineering team will return a detailed specification and quotation within 48 hours.
