Product · LT-MR
Machine Room Elevators
Geared / gearless traction with dedicated overhead machine room
Engineered machine room elevators for Pakistan's demanding built environment.
Liftech Global machine-room (MR) traction elevators place the drive machine, controller and governor in a dedicated overhead room. This is the preferred configuration for high-rise buildings, heavy-load freight lifts and installations where maintenance access, cooling and acoustic isolation are engineering priorities.
MR configurations support the widest range of speeds (up to 4.0 m/s), the highest travel heights (up to 150 m) and the largest payloads. Machines are supplied as PMSM gearless (mid- to high-rise) or geared (heavy freight), always paired with a Monarch NICE 3000+ serial controller.
Where it is deployed.
Why engineers choose this platform.
Widest speed range
Up to 4.0 m/s and 150 m travel with regenerative drive.
Serviceable
Full walk-in machine room simplifies inspection & overhaul.
Acoustic isolation
Machine noise contained in the MR — quieter shaft below.
Heavy payload
Supports geared machines for 5000+ kg freight lifts.
Verified engineering data.
| Parameter | Value |
|---|---|
| Rated load | 630 – 5000 kg |
| Rated speed | 1.0 – 4.0 m/s |
| Travel / stops | Up to 150 m · up to 40 stops |
| Drive system | PMSM gearless or Montanari geared 2:1 |
| Controller | Monarch NICE 3000+ (serial CAN-bus) |
| MR footprint | 1.6–2.4 × shaft footprint |
| MR height | ≥ 2200 mm clear |
Engineering highlights.
- Dedicated overhead machine room with cooling & lighting
- Serviceable overspeed governor & tensioning weight
- Group control up to 8 cars with DCS
- Regenerative VVVF drive option
Safety by design — every layer.
- Automatic Rescue Device (ARD) with battery backup
- Unintended Car Movement (UCM) protection
- Overspeed governor & progressive safety gear
- Machine-room fire-rated door (EI 60)
Codes we design & test to.
- EN 81-20/50
- EN 81-72 (firefighter, optional)
- ISO 8100-1
See it in the field.
Machine Room Elevators: what engineers ask.
End-to-end lifecycle support.
Request a quotation for machine room elevators.
Send us your building drawings and traffic profile — our engineering team will return a detailed specification and quotation within 48 hours.
