Product · LT-MW
Moving Walks
0°–12° inclined · pallet-type · airports & transit
Engineered moving walks for Pakistan's demanding built environment.
Liftech Global moving walks (autowalks / travelators) transport passengers and their luggage over long horizontal or gently inclined distances in airports, transit stations and large retail environments. A pallet-type or belt-type surface delivers a continuous walking speed of 0.5–0.75 m/s, greatly reducing perceived walking distance.
Modules are engineered to EN 115-1:2017 with the same auxiliary brake, skirt safety and speed-monitored handrail systems as escalators. Individual units are supplied up to 100 m long and can be linked to form corridors of any length.
Where it is deployed.
Why engineers choose this platform.
Long distances
Individual units up to 100 m — linked to any total length.
Trolley-friendly
0°–12° incline accepts luggage trolleys & shopping carts.
High throughput
Up to 9,000 pax/hour at 1000 mm pallet width.
Energy saving
IR passenger detector auto-slows the walk when empty.
Verified engineering data.
| Parameter | Value |
|---|---|
| Type | Pallet-type (horizontal / inclined) or belt-type |
| Incline | 0° (horizontal) · 10° · 12° |
| Pallet width | 800 · 1000 · 1200 mm |
| Speed | 0.5 · 0.65 · 0.75 m/s |
| Length | Up to 100 m per unit |
| Throughput | Up to 9,000 pax/hour (1000 mm) |
| Drive | Helical bevel gear, VVVF start/stop |
Engineering highlights.
- Trolley-lock pallets (for inclined units)
- Auto start/stop with IR passenger detector
- LED under-pallet lighting
- Inspection sockets at both landings
- Modular truss for easy transport & site assembly
Safety by design — every layer.
- Auxiliary + operational brake (EN 115-1)
- Skirt-safety switches
- Pallet-level & missing-pallet detection
- Comb-plate impact switch
- Handrail speed monitoring
Codes we design & test to.
- EN 115-1:2017
- EN 115-2
- ISO 8102
See it in the field.
Moving Walks: what engineers ask.
End-to-end lifecycle support.
Request a quotation for moving walks.
Send us your building drawings and traffic profile — our engineering team will return a detailed specification and quotation within 48 hours.
